Name: سوییچ 28 پورت جت استریم تی پی لینک مدل T3700G-28TQ
SKU: 2755
Price: 980000000 IRR
Availability: InStock

ابعاد	44 × 33 × 4.4 سانتیمتر
برند	TP-LINK
گارانتی	گارانتی آواژنگ
Standards and Protocols	IEEE 802.1d, IEEE 802.1p, IEEE 802.1q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Interface	24 10/100/1000Mbps RJ45 Ports, (Auto Negotiation/Auto MDI/MDIX), 4 combo gigabit SFP Slots, Up to 4 10G SFP+ Slots (2 fixed and 2 optional 10G SFP+ Slots), One Console Port
Network Media	10BASE-T: UTP category 3, 4, 5 cable (maximum 100m), 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m), 100BASE-FX: MMF, SMF, 1000BASE-X: MMF, SMF, 10GBASE-LR, 10GBASE-SR
Power Supply	100~240VAC, 50/60Hz
Mounting	Rack Mountable
Max Power Consumption	47W (220V/50Hz)
Max Heat Dissipation	160.36BTU/h
Installable SFP+ Transceivers and Direct Attach Copper (DAC) Cables	TXC432-CU1M, TXC432-CU3M, TXM431-LR, TXM431-SR
Max Number of Stacking Ports Installable	+2SFP
Stacking Speed (Per Port)	20Gbps (Full-Duplex)
No. of Units Per Stack	8
Switching Capacity	Up to 128Gbps for a standalone switch
Bandwidth/Backplane	Up to 320Gbps when 8 units in the stack
Packet Forwarding Rate	Up to 95.2Mpps for a standalone switch
MAC Address Table	32K
Packet Buffer Memory	32Mbits
Jumbo Frame	12KB
Number of Routes	8K
Number of Static Routes	256
Number of IP Interfaces	128
Quality of Service	Support 802.1p CoS/DSCP priority, Support 8 priority queues, Queue scheduling: SP, WRR, SP+WRR, Port/Flow- based Rate Limiting, Voice VLAN
L3 Features	Wire-speed IP forwarding, Static Routing, RIP v1, v2, OSPF v2, ECMP, PIM-SM/PIM-DM/IGMP, DHCP Server/Relay, ARP Proxy, VRRP
L2 Features	IGMP Snooping V1/V2/V3, 802.3ad LACP (Up to 32 aggregation groups, containing 8 ports per group), Spanning Tree STP/RSTP/MSTP, BPDU Filtering/Guard, TC/Root Protect, Loop back detection, 802.3x Flow Control
VLAN	Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs), IEEE 802.1Q VLAN/MAC VLAN/Protocol VLAN/QinQ/Private VLAN/GVRP
Access Control List	L2～L4 package filtering based on source and destination MAC address, IP address, TCP/UDP, ports, 802.1p, DSCP, protocol and VLAN ID, Time Range Based
Security	Broadcast/Multicast/Unknown-unicast Storm Control, DoS Defence, Dynamic ARP inspection (DAI), IEEE 802.1X Port/MAC Based authentication, Radius,Guest VLAN, IP-MAC-Port-VID Binding, Port Security, SSH v1/v2, SSL v2/v3/TLSv1
Management	Web-based GUI and CLI management, SNMP v1/v2c/v3,compatible with public MIBs and TP-LINK private MIBs, RMON (1, 2, 3, 9 groups), DHCP/BOOTP Client, DHCP Snooping, DHCP Option82, CPU Monitoring, Port Mirroring, Time Setting: SNTP, Firmware Upgrade: TFTP & Web, System Diagnose: VCT, SYSLOG & Public MIBS, Dual Image
